EE 313 Linear Systems and Signals - Lecture 13

Lecture

• Lecture slides on Continuous-Time Convolution in PowerPoint format.
  • Lecture Notes
  • Demo: cconvdemo (zip file) from Signal Processing First

• Fall 2018 lecture notes taken by Mr. Houshang Salimian (TA): Part 1 Part 2

Supplemental Information

• Fall 2024
  • Board: Tapped Delay Line Impulse Response DT vs CT
  • Doccam: Tapped Delay Line Impulse Response Plot
• Fall 2023
  • Impulse Responses for an integrator and tapped delay line
• Fall 2021
  • Unit impulse and convolution in discrete-time and continuous-time
  • Tapped delay line and integrator and convolution example

Last updated 11/20/25. Send comments to Prof. Evans at bevans@ece.utexas.edu
